  "p4_src": "p4src/l2_learning_copy_to_cpu.p4",
  "cli": true,
  "pcap_dump": true,
  "enable_log": true,
  "topology": {
    "assignment_strategy": "l2",
    "default":{
      "auto_arp_tables": false
    },
    "links": [["h1", "s1"], ["h2", "s1"], ["h3", "s1"], ["h4","s1"]],
    "hosts": {
      "h1": { },
      "h2": { },
      "h3": { },
      "h4": { }
    },
    "switches": {
      "s1": {
        "cpu_port" : true
      }
    }
  }
}

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198

/* -*- P4_16 -*- */
#include <core.p4>
#include <v1model.p4>

const bit<16> TYPE_IPV4 = 0x800;
const bit<16> L2_LEARN_ETHER_TYPE = 0x1234;

/*************************************************************************
*********************** H E A D E R S  ***********************************
*************************************************************************/
typedef bit<9>  egressSpec_t;
typedef bit<48> macAddr_t;
typedef bit<32> ip4Addr_t;

header ethernet_t {
    macAddr_t dstAddr;
    macAddr_t srcAddr;
    bit<16>   etherType;
}

// 为使得控制器能够获取源MAC地址与入端口
// 定义cpu_t的头部
header cpu_t {
    bit<48> srcAddr;
    bit<16> ingress_port;
}

// 由于克隆出的数据包会失去全部固有元数据
// 因此使用自定义的元数据储存后续将使用的数据
struct metadata {
    bit<9> ingress_port;
}

struct headers {
    ethernet_t   ethernet;
    cpu_t        cpu;
}

/*************************************************************************
*********************** P A R S E R  ***********************************
*************************************************************************/
parser MyParser(packet_in packet,
                out headers hdr,
                inout metadata meta,
                inout standard_metadata_t standard_metadata) {
    state start {
        packet.extract(hdr.ethernet);
        transition accept;
    }
}

/*************************************************************************
************   C H E C K S U M    V E R I F I C A T I O N   *************
*************************************************************************/
control MyVerifyChecksum(inout headers hdr, inout metadata meta) {
    apply { }
}

/*************************************************************************
**************  I N G R E S S   P R O C E S S I N G   *******************
*************************************************************************/
control MyIngress(inout headers hdr,
                  inout metadata meta,
                  inout standard_metadata_t standard_metadata) {
    action drop() {
        mark_to_drop(standard_metadata);
    }

    action mac_learn() {
		// 由于在克隆数据包后 固有元数据将被初始化
		// 因此将入端口号备份进自定义的元数据中
        meta.ingress_port = standard_metadata.ingress_port;
		// CloneType.I2E表示克隆数据包后 直接送到Egree部分处理
		// 100为Session ID
		// 例如控制器连在交换机的7端口上
		// 将在CLI中使用mirroring_add <session> <output_id>
		// 例如mirroring_add 100 7将Session 100与端口7绑定
		// 克隆的数据包将被发至端口7
        clone3(CloneType.I2E, 100, meta);
    }

	// 增加表smac 用于判断数据包的源MAC地址是否已被记录
	// 如果数据包的源MAC在表smac得到hit 则无需操作NoAction
	// 如果未得到hit 则克隆数据包并发送至控制器
    table smac {
        key = {
            hdr.ethernet.srcAddr: exact;
        }

        actions = {
            mac_learn;
            NoAction;
        }
        size = 256;
		// 默认动作为mac_learn 表示hit失败后 上报至控制器
        default_action = mac_learn;
    }

    action forward(bit<9> egress_port) {
        standard_metadata.egress_spec = egress_port;
    }

    table dmac {
        key = {
            hdr.ethernet.dstAddr: exact;
        }

        actions = {
            forward;
            NoAction;
        }
        size = 256;
        default_action = NoAction;
    }

    action set_mcast_grp(bit<16> mcast_grp) {
        standard_metadata.mcast_grp = mcast_grp;
    }

    table broadcast {
        key = {
            standard_metadata.ingress_port: exact;
        }

        actions = {
            set_mcast_grp;
            NoAction;
        }
        size = 256;
        default_action = NoAction;
    }

    apply {
        smac.apply();
        if (dmac.apply().hit){

        }
        else {
            broadcast.apply();
        }
    }
}

/*************************************************************************
****************  E G R E S S   P R O C E S S I N G   *******************
*************************************************************************/
control MyEgress(inout headers hdr,
                 inout metadata meta,
                 inout standard_metadata_t standard_metadata) {
    apply {
		// https://www.jianshu.com/p/044761dc2ea9
		// 当元数据的instance_type为1时 表示为克隆数据包
        if (standard_metadata.instance_type == 1){
			// 只有CPUHeader设置为valid时 该头部在Deparser时才会被封装进数据包
            hdr.cpu.setValid();
			// 填入入端口与源MAC地址信息
            hdr.cpu.srcAddr = hdr.ethernet.srcAddr;
			// 注意此处需要类型转换
            hdr.cpu.ingress_port = (bit<16>)meta.ingress_port;
            hdr.ethernet.etherType = L2_LEARN_ETHER_TYPE;
			// 截断数据包 由于只需链路层和CPU头部 无需其它负载
            truncate((bit<32>)22);
        }
    }
}

/*************************************************************************
*************   C H E C K S U M    C O M P U T A T I O N   **************
*************************************************************************/
control MyComputeChecksum(inout headers hdr, inout metadata meta) {
     apply {

    }
}

/*************************************************************************
***********************  D E P A R S E R  *******************************
*************************************************************************/
control MyDeparser(packet_out packet, in headers hdr) {
    apply {
        //parsed headers have to be added again into the packet.
        packet.emit(hdr.ethernet);
        packet.emit(hdr.cpu);
    }
}

/*************************************************************************
***********************  S W I T C H  *******************************
*************************************************************************/
//switch architecture
V1Switch(
    MyParser(),
    MyVerifyChecksum(),
    MyIngress(),
    MyEgress(),
    MyComputeChecksum(),
    MyDeparser()
) main;

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124

import nnpy
import struct
from p4utils.utils.helper import load_topo
from p4utils.utils.sswitch_thrift_API import SimpleSwitchThriftAPI
from scapy.all import Ether, sniff, Packet, BitField, raw


# 定义CPU Header头部字段
class CpuHeader(Packet):
    name = 'CpuPacket'
    fields_desc = [BitField('macAddr',0,48), BitField('ingress_port', 0, 16)]


class L2Controller(object):
    def __init__(self, sw_name):
		# mininet启动后 将生成topology.json文件 其中是网络配置信息
        self.topo = load_topo('topology.json')
        self.sw_name = sw_name
        self.thrift_port = self.topo.get_thrift_port(sw_name)
		# 从网络配置信息中获取交换机上与控制器通信的端口
        self.cpu_port =  self.topo.get_cpu_port_index(self.sw_name)
		# 控制器交互API接口
        self.controller = SimpleSwitchThriftAPI(self.thrift_port)
        self.init()

    def init(self):
		# 初始化交换机的状态
        self.controller.reset_state()
        self.add_boadcast_groups()
        self.add_mirror()
        #self.fill_table_test()

    def add_mirror(self):
        if self.cpu_port:
			# 将Session 100与交换机上连接控制器的端口绑定
            self.controller.mirroring_add(100, self.cpu_port)

    def add_boadcast_groups(self):
        interfaces_to_port = self.topo.get_node_intfs(fields=['port'])[self.sw_name].copy()
        # Filter lo and cpu port
        interfaces_to_port.pop('lo', None)
        interfaces_to_port.pop(self.topo.get_cpu_port_intf(self.sw_name), None)

        mc_grp_id = 1
        rid = 0
        for ingress_port in interfaces_to_port.values():
            port_list = list(interfaces_to_port.values())
            del(port_list[port_list.index(ingress_port)])
            # 添加组播组
            self.controller.mc_mgrp_create(mc_grp_id)
            # 添加多播组
            handle = self.controller.mc_node_create(rid, port_list)
            # 将多播组与组播组关联
            self.controller.mc_node_associate(mc_grp_id, handle)
            # 将关系写入表broadcast中
            self.controller.table_add("broadcast", "set_mcast_grp", [str(ingress_port)], [str(mc_grp_id)])
            mc_grp_id +=1
            rid +=1

    def fill_table_test(self):
		# 添加L2转发表
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:01'], ['1'])
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:02'], ['2'])
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:03'], ['3'])
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:04'], ['4'])

    def learn(self, learning_data):
		# 进行下发 分别写入smac与dmac表
        for mac_addr, ingress_port in  learning_data:
            print("mac: %012X ingress_port: %s " % (mac_addr, ingress_port))
            self.controller.table_add("smac", "NoAction", [str(mac_addr)])
            self.controller.table_add("dmac", "forward", [str(mac_addr)], [str(ingress_port)])

    def unpack_digest(self, msg, num_samples):
        digest = []
        starting_index = 32
        for sample in range(num_samples):
            mac0, mac1, ingress_port = struct.unpack(">LHH", msg[starting_index:starting_index+8])
            starting_index +=8
            mac_addr = (mac0 << 16) + mac1
            digest.append((mac_addr, ingress_port))
        return digest

    def recv_msg_digest(self, msg):
        topic, device_id, ctx_id, list_id, buffer_id, num = struct.unpack("<iQiiQi",
                                                                          msg[:32])
        digest = self.unpack_digest(msg, num)
        self.learn(digest)
        #Acknowledge digest
        self.controller.client.bm_learning_ack_buffer(ctx_id, list_id, buffer_id)

    def run_digest_loop(self):
        sub = nnpy.Socket(nnpy.AF_SP, nnpy.SUB)
        notifications_socket = self.controller.client.bm_mgmt_get_info().notifications_socket
        sub.connect(notifications_socket)
        sub.setsockopt(nnpy.SUB, nnpy.SUB_SUBSCRIBE, '')
        while True:
            msg = sub.recv()
            self.recv_msg_digest(msg)

    def recv_msg_cpu(self, pkt):
		# 解析接收到的数据包
        packet = Ether(raw(pkt))
		# 链路层类型需为0x1234
        if packet.type == 0x1234:
			# 继续解析其后的cpu_header
            cpu_header = CpuHeader(bytes(packet.load))
			# 将学习到的进行下发
            self.learn([(cpu_header.macAddr, cpu_header.ingress_port)])

    def run_cpu_port_loop(self):
		# 监听端口 获取接收到的数据包
        cpu_port_intf = str(self.topo.get_cpu_port_intf(self.sw_name).replace("eth0", "eth1"))
        sniff(iface=cpu_port_intf, prn=self.recv_msg_cpu)


if __name__ == "__main__":
    import sys
    sw_name = sys.argv[1]
    receive_from = sys.argv[2]
    if receive_from == "digest":
        controller = L2Controller(sw_name).run_digest_loop()
    elif receive_from == "cpu":
        controller = L2Controller(sw_name).run_cpu_port_loop()

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170

/* -*- P4_16 -*- */
#include <core.p4>
#include <v1model.p4>

const bit<16> TYPE_IPV4 = 0x800;
const bit<16> TYPE_BROADCAST = 0x1234;

/*************************************************************************
*********************** H E A D E R S  ***********************************
*************************************************************************/
typedef bit<9>  egressSpec_t;
typedef bit<48> macAddr_t;
typedef bit<32> ip4Addr_t;

header ethernet_t {
    macAddr_t dstAddr;
    macAddr_t srcAddr;
    bit<16>   etherType;
}

// Digest的数据负载部分
struct learn_t {
    bit<48> srcAddr;
    bit<9>  ingress_port;
}

// 自定义的元数据
struct metadata {
    learn_t learn;
}

struct headers {
    ethernet_t   ethernet;
}

/*************************************************************************
*********************** P A R S E R  ***********************************
*************************************************************************/
parser MyParser(packet_in packet,
                out headers hdr,
                inout metadata meta,
                inout standard_metadata_t standard_metadata) {
    state start {
        packet.extract(hdr.ethernet);
        transition accept;
    }
}

/*************************************************************************
************   C H E C K S U M    V E R I F I C A T I O N   *************
*************************************************************************/
control MyVerifyChecksum(inout headers hdr, inout metadata meta) {
    apply { }
}

/*************************************************************************
**************  I N G R E S S   P R O C E S S I N G   *******************
*************************************************************************/
control MyIngress(inout headers hdr,
                  inout metadata meta,
                  inout standard_metadata_t standard_metadata) {
    action drop() {
        mark_to_drop(standard_metadata);
    }

    action mac_learn(){
		// 填充digest的负载部分
        meta.learn.srcAddr = hdr.ethernet.srcAddr;
        meta.learn.ingress_port = standard_metadata.ingress_port;
		// 调用digest将信息直接发送至控制器
		// 第一个参数永远是1
		// 第二个参数是digest的负载
        digest<learn_t>(1, meta.learn);
    }

    table smac {
        key = {
            hdr.ethernet.srcAddr: exact;
        }

        actions = {
            mac_learn;
            NoAction;
        }
        size = 256;
        default_action = mac_learn;
    }

    action forward(bit<9> egress_port) {
        standard_metadata.egress_spec = egress_port;
    }

    table dmac {
        key = {
            hdr.ethernet.dstAddr: exact;
        }

        actions = {
            forward;
            NoAction;
        }
        size = 256;
        default_action = NoAction;
    }

    action set_mcast_grp(bit<16> mcast_grp) {
        standard_metadata.mcast_grp = mcast_grp;
    }

    table broadcast {
        key = {
            standard_metadata.ingress_port: exact;
        }

        actions = {
            set_mcast_grp;
            NoAction;
        }
        size = 256;
        default_action = NoAction;
    }

    apply {
        smac.apply();
        if (dmac.apply().hit){
        }
        else {
            broadcast.apply();
        }
    }
}

/*************************************************************************
****************  E G R E S S   P R O C E S S I N G   *******************
*************************************************************************/
control MyEgress(inout headers hdr,
                 inout metadata meta,
                 inout standard_metadata_t standard_metadata) {
    apply { }
}

/*************************************************************************
*************   C H E C K S U M    C O M P U T A T I O N   **************
*************************************************************************/
control MyComputeChecksum(inout headers hdr, inout metadata meta) {
     apply { }
}

/*************************************************************************
***********************  D E P A R S E R  *******************************
*************************************************************************/
control MyDeparser(packet_out packet, in headers hdr) {
    apply {
        //parsed headers have to be added again into the packet.
        packet.emit(hdr.ethernet);
    }
}

/*************************************************************************
***********************  S W I T C H  *******************************
*************************************************************************/
//switch architecture
V1Switch(
    MyParser(),
    MyVerifyChecksum(),
    MyIngress(),
    MyEgress(),
    MyComputeChecksum(),
    MyDeparser()
) main;

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129

import nnpy
import struct
from p4utils.utils.helper import load_topo
from p4utils.utils.sswitch_thrift_API import SimpleSwitchThriftAPI
from scapy.all import Ether, sniff, Packet, BitField, raw


# 定义CPU Header头部字段
class CpuHeader(Packet):
    name = 'CpuPacket'
    fields_desc = [BitField('macAddr',0,48), BitField('ingress_port', 0, 16)]


class L2Controller(object):
    def __init__(self, sw_name):
		# mininet启动后 将生成topology.json文件 其中是网络配置信息
        self.topo = load_topo('topology.json')
        self.sw_name = sw_name
        self.thrift_port = self.topo.get_thrift_port(sw_name)
		# 从网络配置信息中获取交换机上与控制器通信的端口
        self.cpu_port =  self.topo.get_cpu_port_index(self.sw_name)
		# 控制器交互API接口
        self.controller = SimpleSwitchThriftAPI(self.thrift_port)
        self.init()

    def init(self):
		# 初始化交换机的状态
        self.controller.reset_state()
        self.add_boadcast_groups()
        self.add_mirror()
        #self.fill_table_test()

    def add_mirror(self):
        if self.cpu_port:
			# 将Session 100与交换机上连接控制器的端口绑定
            self.controller.mirroring_add(100, self.cpu_port)

    def add_boadcast_groups(self):
        interfaces_to_port = self.topo.get_node_intfs(fields=['port'])[self.sw_name].copy()
        # Filter lo and cpu port
        interfaces_to_port.pop('lo', None)
        interfaces_to_port.pop(self.topo.get_cpu_port_intf(self.sw_name), None)

        mc_grp_id = 1
        rid = 0
        for ingress_port in interfaces_to_port.values():
            port_list = list(interfaces_to_port.values())
            del(port_list[port_list.index(ingress_port)])
            # 添加组播组
            self.controller.mc_mgrp_create(mc_grp_id)
            # 添加多播组
            handle = self.controller.mc_node_create(rid, port_list)
            # 将多播组与组播组关联
            self.controller.mc_node_associate(mc_grp_id, handle)
            # 将关系写入表broadcast中
            self.controller.table_add("broadcast", "set_mcast_grp", [str(ingress_port)], [str(mc_grp_id)])
            mc_grp_id +=1
            rid +=1

    def fill_table_test(self):
		# 添加L2转发表
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:01'], ['1'])
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:02'], ['2'])
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:03'], ['3'])
        self.controller.table_add("dmac", "forward", ['00:00:0a:00:00:04'], ['4'])

    def learn(self, learning_data):
		# 进行下发 分别写入smac与dmac表
        for mac_addr, ingress_port in  learning_data:
            print("mac: %012X ingress_port: %s " % (mac_addr, ingress_port))
            self.controller.table_add("smac", "NoAction", [str(mac_addr)])
            self.controller.table_add("dmac", "forward", [str(mac_addr)], [str(ingress_port)])

    def unpack_digest(self, msg, num_samples):
        digest = []
		# 跳过digest消息的header部分
        starting_index = 32
        for sample in range(num_samples):
			# 解析出mac0、mac1与入端口号
            mac0, mac1, ingress_port = struct.unpack(">LHH", msg[starting_index:starting_index+8])
			# MAC地址48bits+入端口号16bits=64bits=8bytes
            starting_index +=8
			# 将mac0与mac1拼接成MAC地址
            mac_addr = (mac0 << 16) + mac1
            digest.append((mac_addr, ingress_port))
        return digest

    def recv_msg_digest(self, msg):
        topic, device_id, ctx_id, list_id, buffer_id, num = struct.unpack("<iQiiQi",
                                                                          msg[:32])
        # 解析digest
		digest = self.unpack_digest(msg, num)
        self.learn(digest)
        #Acknowledge digest
        self.controller.client.bm_learning_ack_buffer(ctx_id, list_id, buffer_id)

    def run_digest_loop(self):
        sub = nnpy.Socket(nnpy.AF_SP, nnpy.SUB)
        notifications_socket = self.controller.client.bm_mgmt_get_info().notifications_socket
        sub.connect(notifications_socket)
        sub.setsockopt(nnpy.SUB, nnpy.SUB_SUBSCRIBE, '')
        while True:
            msg = sub.recv()
            self.recv_msg_digest(msg)

    def recv_msg_cpu(self, pkt):
		# 解析接收到的数据包
        packet = Ether(raw(pkt))
		# 链路层类型需为0x1234
        if packet.type == 0x1234:
			# 继续解析其后的cpu_header
            cpu_header = CpuHeader(bytes(packet.load))
			# 将学习到的进行下发
            self.learn([(cpu_header.macAddr, cpu_header.ingress_port)])

    def run_cpu_port_loop(self):
		# 监听端口 获取接收到的数据包
        cpu_port_intf = str(self.topo.get_cpu_port_intf(self.sw_name).replace("eth0", "eth1"))
        sniff(iface=cpu_port_intf, prn=self.recv_msg_cpu)


if __name__ == "__main__":
    import sys
    sw_name = sys.argv[1]
    receive_from = sys.argv[2]
    if receive_from == "digest":
        controller = L2Controller(sw_name).run_digest_loop()
    elif receive_from == "cpu":
        controller = L2Controller(sw_name).run_cpu_port_loop()
